Description
Ensures clean, filtered water with durable, low-maintenance stainless steel construction.
Industries – Reliable Filtration with Stainless Steel Housing
SS304/SS316 Stainless Steel
Offers exceptional corrosion resistance, extending product lifespan by 50% in harsh environments.
Multiple Micron Ratings (1um-20um)
Provides flexible filtration options, catering to various water quality requirements.
High Max Water Flow Rate (20-40m³)
Ensures efficient filtration, reducing downtime and increasing productivity.
1-Year Warranty on Core Components
Guarantees reliable performance and peace of mind for customers.
Features
The Stainless Steel Water Filter Housing is constructed with premium SS304 or SS316 stainless steel, ensuring durability and corrosion resistance. It features multiple micron ratings (1um, 5um, 10um, 20um) for versatile filtration needs. The housing comes in various models (SFF-DS01, SFF-TS01, SFF-DS02, SFF-TS02) with side or top entry options. It has a design pressure of 1MPa, working pressure of 0.8MPa, and can withstand hydrostatic pressure tests up to 1.25MPa. The housing is equipped with a vent (Rc 1/2″ female), pressure gauge (Rc 1/4″ female), and NBR seal ring material for reliable performance.
Benefits
Customers benefit from the long-lasting durability of stainless steel, reducing the need for frequent replacements. The multiple micron ratings allow for precise filtration, ensuring clean water for various applications. The high max water flow rate enhances operational efficiency, while the 1-year warranty provides assurance of product quality. The housing’s design and materials make it suitable for use in food and beverage factories, farms, retail, food shops, and construction works.
Use Cases
This Stainless Steel Water Filter Housing is ideal for industries requiring clean and filtered water, such as food and beverage production, agricultural irrigation, and commercial water treatment. Its corrosion-resistant properties make it suitable for use in harsh environments, ensuring reliable performance over time. The housing’s versatility in micron ratings and entry options caters to a wide range of filtration needs, making it a valuable addition to any water treatment system.
|
Model
|
SFF-DS01
|
SFF-TS01
|
SFF-DS02
|
SFF-TS02
|
|
Material
|
SS304;SS316
|
SS304;SS316
|
SS304;SS316
|
SS304;SS316
|
|
Thickness(mm)
|
2mm
|
2mm
|
2mm
|
2mm
|
|
Type
|
Side Entry BSP2”
|
Side Entry BSP2”
|
Side Entry BSP2”
|
Top Entry 2” Flange
|
|
Diameter of barrel (mm)
|
200
|
200
|
200
|
200
|
|
Design pressure (MPa)
|
1
|
1
|
1
|
1
|
|
Working pressure (MPa)
|
0.8
|
0.8
|
0.8
|
0.8
|
|
Design temperature ℃
|
80
|
80
|
80
|
80
|
|
Hydrostatic pressure test (MPa)
|
1.25
|
1.25
|
1.25
|
1.25
|
|
Amount of eyebolt(pcs)
|
4
|
4
|
4
|
4
|
|
Max water flow rate (m3)
|
20
|
20
|
40
|
40
|
|
Filter area(m2)
|
0.25
|
0.25
|
0.5
|
0.5
|
|
Weight of empty filter housing(kg)
|
28
|
28
|
33
|
35
|
|
Vent
|
Rc 1/2″(female)
|
Rc 1/2″(female)
|
Rc 1/2″(female)
|
Rc 1/2″(female)
|
|
Pressure gauge
|
Rc 1/4″(female)
|
Rc 1/4″(female)
|
Rc 1/4″(female)
|
Rc 1/4″(female)
|
|
Seal ring material
|
NBR ring
|
NBR ring
|
NBR ring
|
NBR ring
|
|
Dimension of filter bag (mm)
|
7*17inch
|
7*17inch
|
7*32inch
|
7*32inch
|
|
item
|
value
|
|
Condition
|
New
|
|
Applicable Industries
|
Food & Beverage Factory, Farms, Retail, Food Shop, Construction works
|
|
Showroom Location
|
None
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Not Available
|
|
Marketing Type
|
Ordinary Product
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
Pressure vessel
|
|
Place of Origin
|
Shanghai
|
|
Weight
|
45kg
|
|
Size
|
113*45*50cm
|
|
Net Weight (KG)
|
30kg
|
|
Product name
|
PP Single Bag Water Filter Housing 1um 5um 10um
|
Why Choose Our Stainless Steel Water Filter Housing?
Our Stainless Steel Water Filter Housing offers exceptional durability and corrosion resistance, ensuring long-lasting performance in harsh environments. With multiple micron ratings and high max water flow rates, it caters to diverse filtration needs, enhancing operational efficiency.
How Does It Benefit Your Industry?
For industries like food and beverage, farms, and retail, our water filter housing ensures clean and filtered water, meeting stringent quality standards. Its reliable performance reduces downtime and maintenance costs, improving overall productivity.
What Makes Our Product Stand Out?
Our Stainless Steel Water Filter Housing stands out with its premium SS304/SS316 construction, multiple micron ratings, and high max water flow rates. The 1-year warranty on core components provides peace of mind, making it a trusted choice for water treatment systems.
