SS316L Lenticular Filter Housing | Stack and Finish Reference

Description

SS316L Lenticular Filter Housing for Module Stack and Surface-Finish Review

This SS316L housing is a configuration reference for compatible lenticular-module filtration. Final selection depends on module diameter and stack height, required flow, allowable pressure drop, operating pressure and temperature, process compatibility, internal surface finish, gasket material, closure design, cleaning method and documentation requirements.

Module Compatibility

Module diameter, stack quantity, sealing arrangement and compression method must match the approved elements.

Flow and Pressure Drop

Capacity depends on media grade, liquid viscosity, solids load and allowable clean and terminal pressure drop.

SS316L Finish

Surface finish and fabrication documentation are specified according to the process and cleaning requirement.

Cleaning Review

Drainability, venting, gasket selection and any CIP or SIP duty require project-specific confirmation.

Selection Information

Provide the liquid, viscosity, filtration objective, module manufacturer and dimensions, stack quantity, flow, pressure, temperature, surface-finish requirement, seals, connections, cleaning method and required documents.

Role in the Filtration System

Use this page as a preliminary configuration reference. Final performance, availability and commercial terms are confirmed only for the approved project specification.
