Custom Dust Filter Bag Dimension Checklist
Custom dimensions should be confirmed from an approved drawing or verified sample before replacement bags are produced.
Dimensions to Record
- Bag diameter and overall length
- Top construction and snap-band details
- Bottom construction and reinforcement
- Seam orientation and stitch requirements
- Cage outside diameter and length
- Tube-sheet hole and collector clearance
Include media, finish, cleaning method, quantity and delivery location with the dimensional data.
Project Routing
For current U.S. replacement inquiries, use the FiltEdge project page. For manufacturing information, review the SFFILTECH filter bag range.
