Description
Providing a high-efficiency, durable, and chemically resistant solution for industrial dust collection needs.
Industries-Eliminate 99.5% Dust Efficiently
750gsm Woven Glass with PTFE Membrane
Enhances filtration efficiency and durability, suitable for high-temperature environments.
Excellent Tensile Strength
Withstands ≥528 lbs/inch in warp and ≥440 lbs/inch in weft, ensuring long-lasting performance.
Superior Air Permeability
Allows 2-5 m³/m²/min at 127Mpa, optimizing airflow and reducing energy consumption.
Chemical Resistance
Stable against most mediums except hydrofluoric acid, strong acids, and strong alkalines.
Features
The Woven Fiberglass Dust Filter Felt Cloth is crafted from 750gsm woven glass with a PTFE membrane, offering exceptional heat resistance up to 260°C continuously and 300°C instantly. It features a thickness of 0.8±0.1mm, ensuring precise filtration. The cloth’s tensile strength exceeds industry standards, with ≥528 lbs/inch in warp and ≥440 lbs/inch in weft. Air permeability is optimized at 2-5 m³/m²/min at 127Mpa, facilitating efficient dust collection.
Benefits
This filter cloth provides industries with a cost-effective and reliable solution for dust collection. Its high heat resistance ensures longevity in harsh environments, while superior tensile strength guarantees durability. The optimized air permeability reduces energy consumption, lowering operational costs. Additionally, its chemical resistance broadens the range of applications, making it suitable for various industrial settings.
Use Cases
The Woven Fiberglass Dust Filter Felt Cloth is widely used in industries such as cement, carbon black, steel, metallurgy, and coal. Its high filtration efficiency, exceeding 99.5%, makes it ideal for back-blow filter bags, ensuring clean air and valuable dust recycling. The cloth’s versatility and durability cater to the specific needs of each industry, providing a tailored solution for dust collection challenges.
|
750gsm woven glass with ptfe mem
|
Meterial
|
||||||
|
E-glass
|
|||||||
|
Warp
|
US glass system
|
DE75 1/2
|
|||||
|
Tex system
|
EC75 66×2
|
||||||
|
Weft
|
US glass system
|
DE75 2/2(T)
|
|||||
|
Tex system
|
EC6 66x2x2(T)
|
||||||
|
Thead Count
|
No./inch
|
48×40
|
|||||
|
No./cm
|
19×16
|
||||||
|
Weight
|
oz/sq yd
|
22
|
|||||
|
g/sqm
|
750(±5%)
|
||||||
|
Thickness
|
mm
|
0.8±0.1
|
|||||
|
Finsh
|
ptfe membrane
|
||||||
|
Tensile Strength
|
Warp
|
lbs/inch
|
≥528
|
||||
|
N/25mm
|
≥2400
|
||||||
|
Weft
|
lbs/inch
|
≥440
|
|||||
|
N/25mm
|
≥2000
|
||||||
|
Air Permeability
|
m³/m²/min at 127Mpa
|
2-5
|
|||||
|
operating Temperature
|
Continuous
|
℃
|
≤260
|
||||
|
Instant
|
℃
|
300
|
|||||
Why Choose Woven Fiberglass Dust Filter Felt Cloth?
Our filter cloth offers unparalleled efficiency in dust collection, with a filtration rate exceeding 99.5%. Its high heat resistance and chemical stability make it suitable for a wide range of industrial applications, ensuring long-term performance and cost savings.
How Does It Enhance Industrial Processes?
By optimizing airflow and reducing energy consumption, our filter cloth improves the efficiency of dust collection systems. Its durability and resistance to harsh conditions minimize downtime and maintenance costs, enhancing overall industrial productivity.
What Industries Benefit Most?
Industries such as cement, steel, metallurgy, and coal benefit significantly from our filter cloth. Its ability to withstand high temperatures and chemical exposure makes it an ideal choice for these demanding environments, ensuring clean air and efficient dust recycling.
