Description
Specifications:
- Filter Media: PVDF membrane
- Pore Size: 0.1 μm, 0.2 μm, 0.45 μm, 1.0 μm
- Length: 10″, 20″, 30″, 40″ (customizable)
- Core/Cage Material: Polypropylene (PP) or Stainless Steel (304/316)
- End Cap Type: DOE, 222/Flat, 222/Fin, 226/Flat, 226/Fin
- Operating Temperature: Up to 85°C (continuous), 121°C for 30 minutes sterilization
- Package: Carton Packing
Applications:
- Ultrapure & Process Water Filtration: Ideal for final filtration in RO and DI systems, ultrapure water systems in electronics and semiconductor industries, and laboratory-grade water systems.
- Chemical Filtration: Perfect for filtering aggressive acids, alkalis, and organic solvents in high-purity chemical processing.
- Food & Beverage Processing: Clarifies and cold sterilizes beverages, filters process water, flavor additives, and ethanol-based solutions.
- Ink, Coating & Paint: Filters solvent-based inks, pigments, varnishes, lacquers, and coatings used in printing, coating, and packaging industries.
- General Industrial Use: Filters compressed air condensate, serves as final filtration before precision equipment, and is used in cleanroom fluid filtration.
Advantages:
- Excellent chemical compatibility
- Withstands high temperatures and steam sterilization
- Available in hydrophilic (for liquids) and hydrophobic (for gases) versions
- Low extractables, ideal for sensitive processes
After-Sales Service: We provide comprehensive after-sales service, including technical support and warranty assistance (specific warranty terms available upon request).
|
item
|
value
|
|
weight (kg)
|
0.5
|
|
core components
|
Media
|
|
brand name
|
SFFILTECH
|
|
warranty
|
Unavailable
|
|
video outgoing-inspection
|
Provided
|
|
machinery test report
|
Provided
|
|
place of origin
|
Shanghai,China
|
|
Product Name
|
PVDF Membrane Filter Cartridge
|
|
Filter Media
|
PVDF (Polyvinylidene Fluoride) membrane
|
|
Pore Size
|
0.1 μm, 0.2 μm, 0.45 μm, 1.0 μm
|
|
Length
|
10″, 20″, 30″, 40″ (customizable)
|
|
Core / Cage Material
|
Polypropylene (PP) or Stainless Steel (304/316)
|
|
End Cap Type
|
DOE, 222/Flat, 222/Fin, 226/Flat, 226/Fin
|
|
Operating Temp.
|
Up to 85°C (continuous), 121°C for 30 minutes sterilization
|
|
Package
|
Carton Packing
|
Why Choose Our PVDF Membrane Filter Cartridge?
Our PVDF Membrane Filter Cartridge stands out due to its excellent chemical compatibility, high-temperature resistance, and ability to withstand steam sterilization. It is available in both hydrophilic and hydrophobic versions, making it suitable for a wide range of applications, from ultrapure water filtration to chemical processing.
What Are the Key Applications?
This filter cartridge is ideal for ultrapure water systems in electronics and semiconductor industries, chemical filtration in high-purity processes, food and beverage processing, ink and coating filtration, and general industrial use such as compressed air filtration.
What Are the Advantages of Buying from Us?
As a factory and supplier, we offer wholesale prices, high-quality products, and comprehensive after-sales service. Our PVDF Membrane Filter Cartridge is designed to meet the highest standards, ensuring reliable performance and long-lasting durability.
