Description
Our MERV 8 air filter with TiO2 photocatalyst provides superior air purification, ensuring clean and healthy indoor environments.
Businesses – Achieve Cleaner Air with MERV 8 Filters
TiO2 Photocatalyst
Breaks down pollutants, enhancing air quality beyond standard filtration.
Anodized Aluminum Frame
Durable and corrosion-resistant, ensuring long-lasting performance.
Special Glass Fiber Media
High dust-holding capacity and low initial resistance for efficient filtration.
Rigorous Testing
Each filter undergoes strict testing to ensure reliability and effectiveness.
Features
The MERV 8 pleated air filter with TiO2 photocatalyst features an anodized aluminum frame for durability. Its special glass fiber filter paper offers high dust-holding capacity and low initial resistance. The filter is rigorously tested to meet high standards. Recommended final pressure drop is 450pa, and it can withstand temperatures up to 100°C. The fire rating is DIN 53438 class F1.
Benefits
Our MERV 8 air filter with TiO2 photocatalyst provides cleaner air by breaking down pollutants, not just trapping them. This leads to a healthier indoor environment, reducing allergens and improving overall air quality. The durable frame and efficient media ensure long-lasting performance, reducing the need for frequent replacements and saving costs in the long run.
Use Cases
This air filter is suitable for a wide range of applications, including commercial buildings, industrial facilities, and institutional settings. It is particularly effective in environments where air quality is critical, such as paint spray booths, industrial coating equipment, high-tech electronics manufacturing, precision instrument facilities, biopharmaceuticals, food hygiene areas, and ventilation and air conditioning systems.
|
Model |
Dimensions |
Media area(m2) |
Face Velocity |
Rated air flow(m3/h) |
Initial pressure drop (pa) |
|||
|
W*H*D |
W*H*D(mm) |
m2 |
m/s |
standard |
standard |
H10 |
H13 |
H14 |
|
SHH610/03-50 |
305*305*50 |
1.6 |
0.5 |
150 |
525 |
≤ 190 |
≤ 250 |
≤ 280 |
|
SHH610/05-50 |
305*610*50 |
3.3 |
0.5 |
300 |
1500 |
|||
|
SHH610/10-50 |
610*610*50 |
6.7 |
0.5 |
600 |
2250 |
|||
|
SHH610/15-50 |
915*610*50 |
10.1 |
0.5 |
900 |
3000 |
|||
|
SHH610/20-50 |
1220*610*50 |
13.5 |
0.5 |
1200 |
1200 |
|||
|
SHH610/03-70 |
305*305*70 |
2.7 |
0.75 |
250 |
2250 |
|||
|
SHH610/05-70 |
305*610*70 |
5.5 |
0.75 |
500 |
3300 |
|||
|
SHH610/10-70 |
610*610*70 |
11.3 |
0.75 |
1000 |
4500 |
|||
|
SHH610/15-70 |
915*610*70 |
17.0 |
0.75 |
1500 |
375 |
|||
|
SHH610/20-70 |
1220*610*70 |
22.7 |
0.75 |
2000 |
750 |
|||
|
SHH610/03-90 |
305*305*90 |
3.7 |
1.0 |
320 |
1500 |
|||
|
SHH610/05-90 |
305*610*90 |
7.5 |
1.0 |
650 |
2250 |
|||
|
SHH610/10-90 |
610*610*90 |
15.4 |
1.0 |
1300 |
3000 |
|||
|
SHH610/15-90 |
915*610*90 |
23.2 |
1.0 |
2000 |
1500 |
|||
|
SHH610/20-90 |
1220*610*90 |
31.1 |
1.0 |
2600 |
3000 |
|||
What Does MERV 8 Mean on Air Filters?
MERV 8 indicates the filter's ability to capture particles between 3 and 10 microns in size, providing efficient air purification for various settings.
Why Choose Our MERV 8 Air Filter?
Our filter combines MERV 8 efficiency with TiO2 photocatalyst technology, offering superior air quality improvement by breaking down pollutants, not just trapping them.
Where Can Our MERV 8 Air Filter Be Used?
It is ideal for commercial, industrial, and institutional applications, including paint spray booths, electronics manufacturing, and biopharmaceuticals, ensuring clean and healthy indoor environments.
