Multi-Cartridge Sanitary Filter Housing for Cleaning and Documentation Review
This stainless steel multi-cartridge housing is a configuration reference for compatible liquid-filtration duties. Final selection depends on the process liquid, required flow, pressure and temperature, cartridge dimensions and quantity, connection standard, surface finish, gasket material, cleaning method and documentation requirements.
Multi-Cartridge Layout
Element quantity should be selected from the required flow, cartridge size, allowable pressure drop and available installation space.
Material Options
SUS304, 316 or 316L should be confirmed against chemical compatibility, cleaning procedures and project specifications.
Closure and Connections
Bolted, flanged or clamp arrangements are matched to the approved pressure, piping and maintenance requirements.
Sanitary Review
Surface finish, drainability, gasket selection and any CIP or SIP requirement must be verified for the intended process.
Selection Information
Please provide the liquid, required flow, operating and design pressure, temperature, target filtration rating, cartridge type and length, connection details, finish requirement, cleaning method and required quality documents. The listed values below are reference specifications and do not replace an approved project datasheet.
Typical Uses
Potential applications include compatible water, food and beverage, chemical, lubricant and process-liquid services. Regulated or high-purity duties require confirmation of materials, finish, cleaning procedure and documentation.
|
item
|
value
|
|
productivity
|
1000L/Hour
|
|
weight (kg)
|
50
|
|
Processing Type
|
filtration
|
|
Power
|
3KW, 5KW
|
|
Voltage
|
220V
|
|
video outgoing-inspection
|
Provided
|
|
machinery test report
|
Provided
|
|
core components
|
PLC
|
|
place of origin
|
Shanghai,China
|
|
brand name
|
SFFILTECH
|
|
Dimension(L*W*H)
|
200*200*800
|
|
Product name
|
Candle Filter Housing
|
|
Material
|
sus304, 316, 316L
|
|
Cartridge filters quantity
|
1 – 160 element/rounds
|
|
Surface treatment:
|
Polished & Sandblast
|
|
Top cap installed type
|
bolts/Flange/Clamp type
|
|
Pecket
|
Wood Box
|
