Description
Our filter housing provides reliable and efficient filtration solutions, ensuring optimal performance in demanding industrial environments.
Industries – Achieve Superior Filtration with Filter Housing
Polyester/Polyester Scrim Material
Enhanced durability and strength, suitable for harsh industrial conditions.
High Air Permeability (12~16 m³/m²/min)
Facilitates efficient air filtration, reducing energy consumption.
Excellent Resistance to Acids, Alkalis, and Oxidizing Agents
Ensures long-lasting performance even in chemically aggressive environments.
Wide Temperature Range (Continuous Dry Heat: 135°C, Moist Heat: 94°C)
Adaptable to various temperature conditions, enhancing versatility.
Features
Our filter housing is constructed with high-quality polyester/polyester scrim material, offering exceptional strength and durability. It features a thickness of 1.9mm and a weight of 500g/sqm, ensuring robust filtration performance. The air permeability ranges from 12 to 16 m³/m²/min, facilitating efficient air flow. Additionally, it exhibits excellent tensile strength in both warp and weft directions, with values exceeding 1000N/5x20cm and 1300N/5x20cm, respectively.
Benefits
By choosing our filter housing, customers can expect a significant improvement in filtration efficiency, leading to reduced energy consumption and lower operational costs. The material’s resistance to acids, alkalis, and oxidizing agents ensures a prolonged lifespan, minimizing the need for frequent replacements. Moreover, the wide temperature range adaptability makes it suitable for various industrial applications, providing flexibility and reliability.
Use Cases
Our filter housing is ideally suited for a range of industrial sectors, including chemical processing, steel manufacturing, waste incineration, thermoelectricity generation, and construction material production. In the chemical industry, it effectively filters out harmful particles and gases, ensuring a safe working environment. For steel plants, it aids in maintaining air quality by capturing dust and other pollutants. Waste incineration facilities benefit from its ability to handle high-temperature gases and particulates, while thermoelectricity plants rely on it for efficient air filtration to protect equipment. Construction material producers utilize our filter housing to control dust emissions during production processes.
|
Specs forpolyester needle felt
|
||||||||||
|
Material
|
Polyester/Polyester Scrim
|
Thickness
|
1.9
|
|||||||
|
Weight(g/sqm)
|
500
|
Density(g/cm³)
|
1.38
|
Air Permeability (m³/m²/min)
|
12~16
|
|||||
|
Warp Tensile Strength(N/5x20cm)
|
>1000
|
Weft Tensile Strenght(N/5x20cm)
|
>1300
|
Moisture Regain(20°C And 65% r. humidity)
|
0.10%
|
|||||
|
Warp Elongation(%)
|
<30
|
Weft Elongation(%)
|
<50
|
Support Combustion
|
Yes
|
|||||
|
Continuous Dry Heat Operation(°C)
|
135
|
Continuous Moist Heat Operation(°C)
|
94
|
Max Short Dry Heat Surge(Short Term)(°C)
|
150
|
|||||
|
Biological(Mildew, Bacteria)
|
fair
|
Alkalis
|
fair
|
Mineral Acids
|
fair
|
|||||
|
Organic Acids
|
fair
|
Oxidising Agents
|
good
|
Organic Solvents
|
good
|
|||||
|
Finishing
|
Singeing-calendering-heat setting
|
|||||||||
|
Product Applications
|
Chemical/ Steel/Waste Incineration/Thermoelectricity/Construction Material
|
|||||||||
|
Usage
|
Air Filter
|
|||||||||
|
Type
|
Filter Felt
|
|||||||||
|
Specialized in supplying
|
||||||||||
|
1. Needle puched felt 2. Woven filtration fabric 3. Filter bags 4. Filter cages 5. Filter tubing automatic production line
|
||||||||||
|
Item
|
Polyproplene filter felt
|
|
Construction
|
Needle felt
|
|
Fibre Composition
|
Polyproplene or nylon
|
|
Micro rating
|
1um 5um 10um 25um 50um 75um 100um 125um 150um 200um 250um 300um
|
|
Continuous Temperature
|
90℃
|
|
Peak Temperature
|
95℃
|
|
Resistance Hydrolysis
|
Excellent
|
|
Resistance to Acids
|
Excellent
|
|
Resistance to Alkalis
|
Excellent
|
|
Resistance to Oxidation
|
Restrict
|
|
PHvalue
|
1-14
|
|
Application
|
Application to food ,flour.sugar,fertilizer,electropating and pesticide industries
|
|
Remark
|
Restrict resistance to oxidation,but excellent resistance to hydrolysis
|
|
Item
|
Dia(inch)
|
length
|
mm
|
|
1#
|
7″
|
17″
|
180X420
|
|
2#
|
7″
|
32″
|
180X810
|
|
3#
|
4″
|
9″
|
102X230
|
|
4#
|
4″
|
15″
|
102X410
|
|
5#
|
6″
|
22″
|
152×559
|
|
Material
|
PE,PP,NMO
|
|
Bag top ring
|
Plastic ring, Stainless steel ring
|
|
Relative filtration pore size
|
0.5, 1,5, 10, 25, 50, 100, 200 ,300µm
|
|
Type
|
various specifications
|
|
Airtight method:
|
Hot Melt, reverse sewing
|
|
Effective filtration area
|
various specifications
|
|
Others
|
special requirement of diameter and collar extension can be customized
|
|
Dust filtration
filter bag
|
Polyester filter bag
Nomex dust filter bag ( nomex scrim or fiber glass scrim)
Pps dust filter bag
P84 dust filter bag
fiber glass filter bag
and so on
|
||||
|
Liquid filtration
|
Micro Polyester filter bag Micro PP filter bag Nylon filter bag Stainsteel filter bag and so on |
||||
|
Machines for dust filtration
|
Automatic filter bag tube line,Semi-Automatic filter bag tube line,Tripe-needle filter bag sewing machine,double need sewing machine, long arm sewing machine,overlock sewing machine,slitting machine,filter bag bottom punching machine,package machines,needle punch line and so on.
|
||||
|
Usagae/Occasion
|
– Biomass power stations
– Chemical and pharmaceutical industry – High temperature dedusting – Coal-fired power stations – Food industry – Non-ferrous metal and steel production – Cement, gypsum and lime industry – Thermal waste treatment |
||||
|
About us
|
1.Trade Assrurance, with trade assurance,you’ll enjoy: 100% product quality protection
100% on-time shipmeng protection
100% payment protection for your covered amount
2.Gold supplier
3.We accept transactions via alibaba.com
4.Payment protection
5.on-time shipment
6.wholesal low MOQS
7.Popular Buying requests for”filter bag”and “Nut milk bag”
|
||||
|
Size and Design
|
Any size is avaiable, we will follow you size and design
|
||||
|
MOQ(small order accept)
|
50pcs is also accept
|
||||
|
Price
|
We are factory(Our factory add for you check at any time)
|
||||
|
Delivery time
|
Samples: usually shiped one day, orders, 2000pcs filter bags mass 7-15days.biggest order depengds on your quantity.
|
||||
|
Package Detail
|
We have general packing,paper carton with plastic bag inside, some time with pallets.
|
||||
|
Warm Tips
|
More products details,our advantage,package detail,delivery time, samples and so on
|
||||
Why Choose Our Filter Housing?
Our filter housing stands out due to its exceptional durability, high air permeability, and resistance to various chemicals. It is designed to withstand harsh industrial conditions, ensuring reliable and efficient filtration.
How Does It Benefit Industries?
Industries can benefit from reduced energy consumption, lower operational costs, and prolonged equipment lifespan. The filter housing's adaptability to different temperature ranges enhances its versatility, making it suitable for various applications.
What Makes It Different from Competitors?
Unlike competitors, our filter housing is constructed with high-quality materials that offer superior strength and durability. Its excellent resistance to acids, alkalis, and oxidizing agents ensures long-lasting performance, setting it apart in the market.
