Description
Enhance industrial filtration efficiency and separation quality with our premium felt filter.
Industries – Achieve Efficient Separation with Felt Filter
High-Quality P84 Fiber
Ensures superior filtration performance and durability.
550gsm Felt Area Weight
Provides robust filtration capability for heavy-duty industrial applications.
250 m³/m²/min Air Permeability
Optimizes air flow while maintaining effective filtration.
High Breaking Strength
800N/5cm (MD) and 1000N/5cm (CMD) for long-lasting use.
Features
Our felt filter cloth is crafted from high-quality P84 fibers, featuring a 550gsm felt area weight and a thickness of 2.8mm. It boasts excellent air permeability of 250 m³/m²/min at 12.7mmH2O, ensuring efficient air filtration. The filter cloth exhibits high breaking strength, with 800N/5cm in the machine direction (MD) and 1000N/5cm in the cross-machine direction (CMD), along with breaking elongations of 25% (MD) and 35% (CMD). It also maintains minimal dry shrinkage (<1%) at 130°C in both directions, ensuring dimensional stability.
Benefits
The felt filter cloth provides exceptional filtration efficiency, reducing particulate matter in industrial settings. Its high breaking strength and elongation properties ensure durability and longevity, even under demanding conditions. The minimal dry shrinkage guarantees consistent performance over time, reducing the need for frequent replacements. This translates to cost savings and improved operational efficiency for industries relying on effective air filtration and separation.
Use Cases
Our felt filter cloth is ideal for industrial filtration applications, including dust collection systems, bag filters, and other separation processes. It is particularly suited for industries such as cement production, steel manufacturing, power generation, and chemical processing, where efficient air filtration and particulate removal are critical. The cloth’s high-temperature resistance (operating temperatures <260°C) makes it suitable for harsh industrial environments.
|
Item
|
550gsm p84 filter felt
|
|
Construction
|
Needle felt
|
|
Fibre Composition
|
P84
|
|
Scrim Composition
|
P84
|
|
Felt Area Weight
|
550g/m2(±5%)
|
|
Thickness
|
2.8 mm
|
|
Mean Air Permeability
|
250 m3/m2/min 12.7mmH2O
|
|
Breaking Strength-MD(warp)
|
800 N / 5cm
|
|
Breaking Strength-CMD(weft)
|
1000 N / 5cm
|
|
Breaking Elongation( N/5cm)-MD(warp)
|
25%
|
|
Breaking Elongation( N/5cm)-CMD(weft)
|
35%
|
|
Dry Shrinkage MD(130℃warp)
|
<1 %
|
|
Dry Shrinkage CMD(130℃weft)
|
<1 %
|
|
Operating Temperatures
|
<260 deg C
|
|
Recommended Maximum Continuous
|
240deg C
|
|
Recommended Maximum Surge
|
260deg C
|
|
Finish
|
Heat set, singed, calendared
|
Why Choose Our Felt Filter?
Our felt filter cloth is designed for industrial applications requiring efficient air filtration and separation. Its high-quality P84 fibers, robust construction, and excellent air permeability make it ideal for demanding environments. The cloth's durability and minimal dry shrinkage ensure long-lasting performance, reducing maintenance costs and downtime.
Key Features of Our Felt Filter
The felt filter cloth features a 550gsm felt area weight, 2.8mm thickness, and 250 m³/m²/min air permeability. It has high breaking strength and elongation properties, along with minimal dry shrinkage. These features combine to provide superior filtration efficiency and durability.
Applications of Our Felt Filter
Our felt filter cloth is widely used in industries such as cement production, steel manufacturing, power generation, and chemical processing. It is suitable for dust collection systems, bag filters, and other separation processes where efficient air filtration is essential.
